SMC Coaxial Connectors
Interface mating dimensions
Plug
Letter
Millimeters [Inches]
Maximum
Minimum
A
B
C
D
E
F
3.73 [.147]
0.00
3.81 [.150]
0.30 [.012]
3.40 [.134]
-
3.15 [ .124]
2.97 [.110]
-
3.10 [.122]
3.40 [.134]
5.92 [.233]
2.06 [.081]
-
3.05 [.120]
-
G
H
J
2.00 [.079]
2.79 [.110]
Jack
Letter
Millimeters [Inches]
Maximum
Minimum
A
B
C
D
E
F
2.08 [.082]
3.63 [.143]
-
2.16 [.085]
3.71 [.146]
0.25 [.010]
3.38 [.133]
0.53 [.021]
-
3.12 [.123]
0.48 [.019]
0.61 [.024]
3.40 [.134]
0.00
G
H
J
3.76 [.148]
0.30 [.012]
3.66 [.144]
-
3.40 [.134]
5.94 [.234]
K
53
Note: 1. I.D. To meet VSWR and contact resistance when mated with .48/.53 mm dia. Pin.
