Panel Receptacle/Terminal Flush to Below Flange
Panel Mount Plug Receptacle - 4 Hole Sq. Flange - Terminal Flush to Below Flange
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
SMA1551K1-3GT50G-.015-50 N/A
Gold
Teflon
N/A
Remark: Pin size of d = .305 mm [.012”],
.381 mm [.015”],
.457 mm [.018”]
Panel Mount Plug Receptacle - 2 Hole Flange - Terminal Flush to Below Flange
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
SMA1551L1-3GT50G-.015-50 N/A
Gold
Teflon
N/A
Remark: Pin size of d = .305 mm [.012”],
.381 mm [.015”],
.457 mm [.018”]
Panel Mount Jack Receptacle - 4 Hole Sq. Flange - Terminal Flush to Below Flange
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
SMA6551K1-3GT50G-.015-50 N/A
Gold
Teflon
N/A
Remark: Pin size of d = .305 mm [.012”],
.381 mm [.015”],
.457 mm [.018”]
Panel Mount Jack Receptacle - 2 Hole Flange - Terminal Flush to Below Flange
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
SMA6551L1-3GT50G-.015-50 N/A
Gold
Teflon
N/A
Remark: Pin size of d = .305 mm [.012”],
.381 mm [.015”],
.457 mm [.018”]
45
For Reversed Polarized connectors contact local Amphenol Sales Branch.
