SSMB Coaxial Connectors
Amphenol SSMB Serie is a 4 Ghz interconnect family for high frequency devices.
The connectors use a snap-on connection and when plugged held together by a groove and tongue
arrangement.
The design permits quick connection and disconnection in small spaces.
Electrical Specifications
Impedance
50 ohm
Frequency Range
Working Voltage
Dielectric Withstanding Voltage
VSWR
0-4 GHz
RG- 178, RG- 316, .85": 250 VRMS max. at sea level
RG-178, RG-316, .85": 500 VRMS min. at sea level
Straight 1.3 max.
Right Angle 1.5 max.
Contact Resistance
Insulator Resistance
Center Contact: 6 Milliohms max.
Outer Contact: 2.5 Milliohms max.
1000 Megohms min.
Material Specifications
Parts Name
Material
Finish
Body, Metal Parts
Outer Contact Of Plug
Brass per QQ-B-626
Nickel or Gold per requirement
Beryllium copper, per QQ-C-530
Brass per QQ-B-626
Beryllium copper, per QQ-C-530
PTFE
Gold plated
Center Contacts
Male
Gold plated
Female
Gold plated
Insulators
None
Crimp Ferrules
Annealed copper
Nickel or Gold per requirement
Mechanical Specifications
Engagement Force
Disengagement Force
Contact Retention
Durability (Mating)
6 lbs. Max.
2 lbs. min.
2 lbs. min.
500 cycles min.
