Filtered Coaxial Connectors
Amphenol's 456 Series of RF connectors provides capacitive decoupling between the connector
body and the mounting panel. EMI on the coaxial shield is shunted to the chassis ground through
capacitors, while not affecting the DC and power supply frequencies. This reduces ground loop
problems and provides a mechanism to harmlessy dissipate ESD to chassis ground.
The RF parameters of these connectors are the same as their non-filtered counterparts.
Filtering does non affect the signal contact, but only the shell-to-ground connection.
Capacitively decoupled RF-connectors are intermateable and interchangeable with standard
non-filtered versions
Electrical Specifications
Capacitance
10.000 pF
Volting rating
200VDC
Dielectric withstanding voltage
Filter insurtion loss (dB)
(per Mil-STD-220
600 VDC (1000 VDC for rear Mount)
1 MHZ
4
16
18
25
30
30
5 MHZ
@25 C and no load)
10 MHZ
30 MHZ
50 MHZ
1000 MHZ
Other capacitance values are available. Consult Amphenol.
Mechanical Specifications
Parts Name
Material
Finish
Center
Male
Brass
Gold plated
Gold plated
Nickel
Female
Beryllium Copper
Brass
Metal parts
Insulators
UL File #
Noryl or Teflon
None
E135615
LR68598
CSA File #
183
