1.6/5.6 Coaxial Connectors
The Amphenol 1.6/5.6 connectors feature a snap-on mating face, which allows easy connection
and disconnection.
This 75 ohm miniature connector series is ideal for use in the telecommunication industry.
Electrical Specifications
Impedance
75 ohm
Frequency range
Working voltage
Dielectric withstanding voltage
VSWR
0 -1 GHz
335VRMS max. at sea level
1000 VRMS min. at sea level
Straight: 1.3 max.
Right angle: 1.5 max.
Center contact: 4 milliohms max.
Outer contact: 2 milliohms max.
1000 Megaohms min.
Contact resistance
Insulation resistance
Material Specifications
Parts Name
Material
Finish
Body & other metal parts
Male (plug)
Brass per QQ-B-626
Outer contacts:
Nickel / gold
Gold
Phosfor bronze per QQ-B-750
Center contacts:
Gold
Gold
Brass per QQ-B-626
Center contacts:
Female (jack)
Phosfor Bronze per QQ-B-750
PTFE
Insulator
None
Crimp ferrule
Annealed copper
Nickel or gold per requirement
Note: Other material/finish is available on request.
Mating
M9x0.5 threaded coupling
Contact retention
Durability (mating)
6 lbs. Min.
500 cycles min. (for Beryllium Copper female contact only)
