Twin Coaxial Connectors
The Connex TWINAX connectors are designed for use on IBM systems 34 and 38 installations.
They can interface IBM host-compatible network communications where minimum cross-talk and
balanced circuits are necessary in interconnecting work stations.
TWINAX-polarized key and keyway construction, threaded coupling, 0-200 MHz range, 500 V peak
voltage rating.
Twin-BNC-polarized contact design (one female, one male), 2 stud bayonet coupling, captivated
contacts, 0-100 MHz range, 100 V peak voltage rating.
Electrical Specifications
Impedance
Used with 78 ohm/95 ohm twin conductor cable
Keyway polarization and non-polarized:
0-200 MHz, 0-500 MHz with caution
Frequency Range
Contact polarization: 0-100 MHz
Voltage Rating
Keyway polarization and non-polarization: 500 volts peak
Contact polarization: 100 volts peak
*TWINAX connectors keyway construction meet applicable sections MIL-C-3655.
Material Specifications
Parts Name
Center
Material
Finish
Male
Brass
Gold or Silver plated
Gold or Silver plated
Contact
Female
Phosphor Bronze (nominal) or
Beryllium Copper
Brass
Metal parts
Insulators
Nickel
None
None
PBT polyester or noryl
Silicone rubber or Synthetic rubber
Clamp gaskets
161
