UHF/Mini-UHF Coaxial Connectors
The Amphenol UHF/MINI-UHF connectors are popular and economical, used when impedance
mating is not required. General purpose units are designed to operate satisfactorily op to 500
MHz. They have a peak voltage rating of 500 volts.
Electrical Specifications
MINI-UHF Series
Impedance
50 ohm nominal
0-2.5 GHz
Frequency Range
Working Voltage
Dielectric Withstanding Voltage
VSWR
335 volts rms
1000 volts rms
1.25 max. 0-2.5 GHz
5000 megohms (min)
Insulation Resistance
UHF Series
Impedance
None-constant
0-500 MHz
Frequency Range
Voltage Rating
500 volts peak
Material Specifications
Parts Name
Material
Brass
Finish
Center
Male
Gold or Silver plated
Gold or Silver plated
Nickel or Silver plated
None
Contact
Female
Brass or Phosphor Bronze
Brass or Zinc diecast
Metal parts
Insulators
Crimp ferrule
Teflon, PBT polyester, Phenolic
Annealed Copper
Nickel or Silver plated
145
*Note: Silver-plated body is only available for special requirements
