N Coaxial Connectors
N Coaxial Connectors
The Amphenol N connectors with screw coupling are fully interchangeable with N connectors made
to the MIL-C-39012 specification. Designed for use in all systems where very good R.F. and
mechanical performance is critical, whether it be at low or high frequencies.
Plating for intermodulation problems
Intermodulation problems have long been a serious concern for the telecommunications market.
The elimination of all nickel plating on N series connectors has gone a long way to solve this
problem. Amphenol offers both silver-plated (no nickel undercoat on body or under 30 µ" gold
center contact) and Nexcote-plated connectors. Nexcote is our trade name for the popular white
bronze plating, and is fully compatible with all other commercial tri-alloy platings on the market.
Electrical Specifications
Impedance
50 ohm nominal
Frequency
0-11 GHz
Voltage Rating
Dielectric Withstanding Voltage
VSWR
1500 Volts peak
2500 Volts rms
1.3 max. 0-11 GHz
Center contact 1.0 milliohm
Outer contact 0.2 milliohm
5000 megohms (min)
Contact Resistance
Insulation Resistance
Note: 75 ohm series connectors are not intermateable with the 50 ohm series.
Material Specifications
Parts Name
Material
Finish
Center
Male
Brass
Gold or Silver plated
Gold or Silver plated
Contact
Female
Phosphor Bronze (nominal) or
Beryllium Copper
Brass
Metal parts
Nickel*
None
Insulators
Teflon
Clamp gaskets
Crimp ferrules
Sillicone rubber, Synthetic rubber
Annealed copper
None
Nickel*
119
