MMCX Coaxial Connectors
All connector bodies, unless otherwise noted, are machined brass, 3µ” gold-plated.
All insulators are Teflon.
All center contacts are 30µ” gold plated.
All dimensions are in millimeters and [inches].
Direct Solder Attachment for Semi-Rigid .047" and .085" Cable
Straight Solder Plug - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
MMCX1181A1-3GT30G-11-50
MMCX1181A1-3GT30G-13-50
11
13
Gold
Gold
Teflon
Teflon
50
50
N/A
N/A
Assembly Instruction C - page 211
Assembly Instruction E - page 213
Right Angle Solder Plug - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
MMCX1182A1-3GT30G-11-50
MMCX1182A1-3GT30G-13-50
11
13
Gold
Gold
Teflon
Teflon
50
50
N/A
N/A
Assembly Instruction F - page 214
Straight Solder Jack - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
MMCX6181A1-3GT30G-11-50
MMCX6181A1-3GT30G-13-50
11
13
Gold
Gold
Teflon
Teflon
50
50
N/A
N/A
Assembly Instruction C - page 211
Assembly Instruction E - page 213
9
For Reversed Polarized connectors contact local Amphenol Sales Branch.
