CR6848
Absolute Maximum Ratings
Symbol
Parameter
Rating
40
Unit
V
VDD
Supply voltage Pin Voltage
IOVP
VFB
VSEN
PD
VDD OVP maximal enter current
Input Voltage to FB Pin
Input Voltage to SEN Pin
Power Dissipation
ESD Capability, HBM Model
ESD Capability, Machine Model
20
mA
V
V
mW
V
V
-0.3 to 6V
-0.3 to 6V
300
2000
200
20 second
220
℃
Lead Temperature
(Soldering)
SOT-23-6L
10 second
DIP-8
TL
260
℃
℃
TSTG
Storage Temperature Range
-55 to + 150
RECOMMENDED OPERATION CONDITION
Symbol
VDD
RI
Parameter
Min ~ Max
11~20
Unit
V
VDD Supply Voltage
RI PIN Resistor Value
Operation Ambient Temperature
Output Power
58~120
-20~85
0~60
K ohm
℃
TOA
PO
W
FPWM
Frequency of PWM
48~100
kHz
