MINIATURE
GENERAL SPECIFICATIONS MINIATURE REED RELAYS
REED
OUTLINE DIMENSIONS
1.15 Max.
(29.2)
DIMENSIONS SHOWN ARE IN INCHES AND ( MILLIMETERS )
.355
(9.0)
Slotted holes for
Terminal Pins.
.125 (3.2) Typ.
1.00
(25.4)
.900
(22.86)
SIZE IV
.700
(17.8)
SIZE III
.500
(12.7)
.400
(10.16)
SIZE II
SIZE I
.075
(1.9)
.050
(1.27) Typ.
BOTTOM VIEW ALL SIZES
.100
(2.54) Typ.
STANDARD PRINTED CIRCUIT RELAY HAS 1.00" X 0.1" GRID SPACING
SIZE I
RELAY CLASS
131
101/193
104/193
134
CONTACT CONFIGURATION:
Mercury
(SPDT)
Mercury
DPDT
SPDT, DPDT
for 104 Series
SPST-NO
SPST-NO
Latching
(SPST-NO)
3PST-NO
Latching
SPST-NO
or
DPST-NO
Mercury
SPDT,DPDT,
3PDT,4PDT
(193 Series)
up to 6PST-NO
SIZE II
50VA
50VA
CONTACT RATING MAX. (Resistive Load):
SWITCHING VOLTAGE MAX.
SWITCHING CURRENT MAX.
CARRY CURRENT MAX.
4VA
10 VA
500 VDC
2 AMPS
3 AMPS
500 VDC
2 AMPS
3 AMPS
100 VDC
0.5 AMPS
1 AMPS
200DC/130 AC
0.5 AMPS
2 AMPS
INITIAL CONTACT RESISTANCE
100 Milliohms Max. Contact
resistance Stability ± 10% over Life.
200 Milliohms Max.
( IN MILLIOHMS ):
INSULATION RESISTANCE (Ohms)
1010 Min.
1010 Min.
109 Min.
TESTED AT 100 VDC:
SIZE III
DIELECTRIC STRENGTH:
MIN. ACROSS OPEN CONTACTS:
MIN. BETWEEN MUTUALLY
INSULATED POINTS:
1000 VDC
1000 VDC
1000 VDC
1000 VDC
200 VDC
500 VDC
CAPACITANCE: ( non-shielded relay)
ACROSS OPEN CONTACTS:
OPEN CONTACTS TO COIL:
.
3pf Typical
Form "A" 2.0 pF Typ.
Form "C" 3.0pF Typ.
.3pF
2.0 pF
3.0pF
.9pF
2.0 pF
2.5pF
CLOSED CONTACTS TO COIL:
TEMPERATURE:
MAX. AMBIENT OPERATING (˚C )
TEMPERATURE:
85 ˚C or ( 120 ˚C -70˚ x [ Coil Power]) whichever is lower
SIZE IV
- 37˚C
- 40˚C
MIN. AMBIENT OPERATING ( ˚C )
- 40˚C to + 105˚C
- 60˚C to + 105˚C
STORAGE TEMPERATURE:
MOUNTING POSITION:
Vertical ± 15˚
ANY
40 x 108
3 x 108
at low level
50 x 108
LIFE AT RATED LOAD:
With appropriate Contact protection
( End of life 1 Ohm )
10 Million Operations
100 Million Operations
at Low level
5 x 108
at low level
OPERATE TIME: (Typical- in Micro-Sec.]).
1.0 mS, for N.O.
1.0 mS, for N.C.
2300 µS
2000 µS
2.0 mS, for
N.O.
TYPICAL RELEASE TIME: (in Micro-Sec.)
Diode Suppression:
1.0 mS, for N.O.
1.5 mS, for N.C.
1.0 mS for NO
1.5 mS for NC
2.0 mS
2.5 mS
No Suppression:
PACKAGING:
Dust covered, Epoxy Encapsulated is Standard.
PAGE 76
