Magnecraft Struthers-Dunn
MINIATURE P.C. BOARD RELAYS
RELAY SERIES
1330 & 1335
76
NEW!
SEE SECTION 10
FOR
MATING SOCKETS
MINIATURE SIZE
EPOXY SEALED IMMERSION
CLEANABLE.
FEATURES
ENCLOSED SEE THRU COVER
WITH P.C. TERMINALS.
MEETS 8 MILLIMETER
SPACING COIL TO CONTACTS
AC OR DC OPERATION
MEETS 4KV DIELECTRIC
WITHSTANDING VOLTAGE.
5 AMP RESISTIVE OR 3 AMP
INDUCTIVE SWITCHING.
CONTACT DATA
DPDT
SPDT, DPDT
SPDT
CONTACT CONFIGURATION:
UL RATED - 5A, 120VAC, NON
UL RATED - 5A, 30 VDC
3A, 120VAC INDUCTIVE.
1/8 HP, 120 VAC
10 AMPS @
250 VAC/
30 VDC
16AMPS @
240 VAC/
24 VDC
MAXIMUM ALLOWABLE
CONTACT LOAD:
CONTACT MATERIAL:
SILVER CADMIUM OXIDE
SILVER CADMIUM OXIDE
50 MILLIOHMS (INITIAL)
CONTACT RESISTANCE:
INSULATION
100 MILLIOHMS MAX.
(INITIAL)
CHARACTERISTICS
DIELECTRIC STRENGTH
1500 V rms
4000 V rms
COIL DATA
AC - VOLTAGE:
DC - VOLTAGE:
POWER:
VA,: (AC)
WATTS,: (DC)
24, 120 VAC
12, 24 VDC
SPECIAL ORDER
5,6, 12, 24 & 48 VDC
1.2 VA
1.2 W
520 MILLIWATTS
GENERAL DATA
AMBIENT TEMPERATURE
OPERATIONAL:
- 45˚ C to + 70˚ C
- 20˚ C to + 70˚ C
STORAGE:
TIMING VALUES
OPERATE:
20 MILLISECONDS
20 MILLISECONDS
15 MILLISECONDS
10 MILLISECONDS
RELEASE:
LIFE
AC, 50 M. DC, 100M OPERATIONS
100,000 OPERATIONS
MECHANICAL:
ELECTRICAL:
20 MILLION OPERATIONS
150,000 OPERATIONS
H
W
L
H
W
L
DIMENSIONS
.905 X .728 X 1.07
.811 X .512 X 1.14
APPROVALS
LIMITED RATINGS
US
C
PAGE 63
PAGE NUMBER
PAGE 61, 62
PAGE 43
