SERIES
INDUSTRIAL PLUG-IN ALARM RELAY 5 AMP, 2 POLE
RSX 1800
The RSX1800 Series Alarm Relay consists of a pair of 2 pole or 3 pole
relays enclosed in a clear plastic cover. Wired to a 12 Pin Industrial plug.
The relay is wired so that it performs the basic functions of Interfacing between
a alarm point and an alarm light and/or an acoustic sounding device.
The RSX1800 operates from a normally closed trouble contact, while the
RSX1800Z operates from a normally open trouble contact. Either a sustained
or momentary alarm condition will energize the relay when signalled by an
external trouble contact. The Alarm can be allowed to continue until the
trouble has been corrected, at which time it automatically resets.
2.625
(66.6)
2.593
(65.5)
3.406
(86.5)
0.10 Dia. x .435 (2.54 x 11)
Typical of all Pin Dimensions
.435
(11)
LOCKING
CLIP
8
5
10
9
4
7
6
12 11
1.468
(37.2)
1
2
3
COIL DATA
Measured at 25˚C
AC Coils, 50/60Hz
Ohms mA
AC Coils, 50/60Hz
Volts Ohms mA
Volts
6
12
24
6
12
24
200
100
59
35
150
560
10.7
41.1
170
170
80
43
115-125
120
10
11,000
4500
10.5
Struthers-Dunn
ORDERING CODE
Typical Type No.
RSX1800 S 120A
Series
219 Industrial plug-in style Alarm relay
5 Amp, 2 Pole
Design for Trouble Contacts
Operate from N.C. trouble contact- CODE S*
Operate from N.O. Trouble contact- CODE Z*
Coil Voltage
AC: 6, 12, 24, 120, (Add "A")
DC: 6, 12, 24 110-125 (Add "D")
* Codes "S" & "Z" are 120 VAC only. All other codes are
"AD" for NC input or "ZZ" for NO input.
SEE SECTION 10 FOR MATING SOCKETS
PAGE 35
