SERIES
300 VOLT GENERAL PURPOSE PLUG-IN RELAY
219
219 GENERAL SPECIFICATIONS
COIL
Pull-in, min. AC
Pull-in min. DC
Overvoltage, max.
CONTACTS
85% of Nominal Voltage
80 % of Nominal Voltage
110% of nominal, voltage
Contact Material:
Silver Cadmium Oxide, Gold diffused
(Standard)
TIMING
Operate Time:
Release Time:
25 mS Max. @ Nominal Voltage.
20 mS Max. @ Nominal Voltage.
DIELECTRIC STRENGTH
All Mutually Insulated Points:
Insulation :
1500 V rms
1/4" over surface, 1/8" thru Air
TEMPERATURE
Rated Operation:
-10˚C to +60˚C
LIFE EXPECTANCY
Mechanical:
10 Million Operations no load
Electrical:
100,000 Operations @ Rated Load.
MISCELLANEOUS
Enclosure:
Operating Position:
Weight:
Clear polycarbonate.
Vertical, Contacts Up
8.5 oz. (241 g) approx.
COIL SPECIFICATIONS @ 25˚C
CONTACT RATINGS
DC RELAYS, 1.8 WATTS (2.5 W @ 125VDC)
AC RELAYS 50/60 HZ (COIL DATA @ 60HZ Voltage
BREAK
Resistance
Ohms
Resistance
Milliamperes
Cold Hot
Nominal
Voltage
6
12
24
Milliamperes
Cold Hot
Nominal
Voltage
6
12
24 (28)*
32
VOLTS
MAKE CARRY
RESISTIVE INDUCTIVE
Impedance
Ohms
7.2
27
120
Ohms
± 10%
1.1
10A
10A
24 VDC
120 VAC
240 VAC
28 VDC
125 VDC
30A
30A
30A
30A
30A
10A
10A
10A
10A
10A
± 10%
3A
10A
5A
840
410
200
40
15.5
304
147
77
1500
750
375
75
385
189
96
1A
4.2
15.5
540
63.5
250
375
3A
0.1A
10A
0.5A
For versions with suffix "69"
Permanent Magnet Blowouts
62
120
240
2700
13,400
86
2100
17
115/125* 6200
16
32
20
0.5A
1.5A
150 mA
0.5A
125 VDC SM
125 VDC DM
250 VDC SM
250 VDC DM
10A
10A
10A
10A
1.5A
4A
0.5A
1.5A
30A
30A
30A
30A
* Note: Stock 24 Vdc and 115 Vac relays have nameplates stamped 24-28
and 115-125 Vdc respectively. These relays operate at 80% of the lower
voltages and operate within allowable temperature rises at higher voltages.
250 Vdc - Use 125 Vdc relay and series resistor (6000 Ω, 5 W) not supplied.
Struthers-Dunn
ORDERING CODE
Typical Type No.
219 XBX P L -24D
Series
219 Industrial plug-in style
Contact Arrangements
XBX (DPDT)
ABA (DPDT + 1 Pole-NO & 1 Pole NC)
BBX (2 Pole-NO & DPDT)
XDX (4 PDT)
FXX (6 Pole-NO)
DXB (4 Pole-NO & 2 Pole-NC)
Standard Features
Polycarbonate Cover- CODE "P"
Optional Features
Indicator Lamp - CODE "L"
Manual Actuator- CODE "M"
130˚C Coil - CODE "U"
Bifurcated Contacts - CODE "33"
Perm. Magnet Blowout- CODE "69"
Coil Voltage
AC: 6, 12, 24, 120, 240 (Add "A")
DC: 6, 12, (24-28), 32, 115/125 (Add "D")
SEE SECTION 10
FOR
Coil Voltages & Frequencies must be specified.
MATING SOCKETS
