SERIES
300 VOLT GENERAL PURPOSE PLUG-IN RELAY
219
THE SERIES 219 GENERAL PURPOSE INDUSTRIAL PLUG-IN RELAYS FEATURE
12 PIN AND 14 PIN BASES. THE COIL IS ENCAPSULATED FOR PROTECTION.
NUCLEAR QUALIFIED VERSIONS ARE AVAILABLE. CONSULT FACTORY.
UL Recognized
File No. E13224
OPTIONAL MANUAL ACTUATOR
WIRING DIAGRAMS
BOTTOM VIEW
2.625
.250
(66.6)
(6.35)
219XBXP
(DPDT )
1
6
2.593
(65.5)
3.406
(86.5)
12
7
219BBXP
(DPDT + 2 N.O.)
.435
(11)
1
LOCKING
CLIP
6
12
7
1
2
3
4
9
5
8
6
7
1.468
(37.2)
0.10 Dia. x .435 (2.54 x 11)
Typical of all Pin Dimensions 12
10
11
219ABAP
(DPDT + 1NO & 1 NC )
1
6
7
MODELS AVAILABLE
14 PIN
219XDXP
219FXXP
CONTACTS
4PDT
6P-NO
4P-NO + 2P-NC
12 PIN
219BBXP
219XBXP
CONTACTS
DPDT + 2 NO
DPDT
12
219ABAP DPDT + 1 NO & 1 NC 219DXBP
Make before break and other Contact configurations available
limited only by the number of terminal pins.Contact Factory.
OPTIONAL MANUAL ACTUATOR
219FXXP
(6P-NO )
3.062
(77.77)
.250
(6.35)
1
7
8
2.593
(65.5)
14
3.406
(86.5)
219XDXP
(4PDT )
1
7
8
.435
(11)
LOCKING
CLIP
14
11 10
14 13 12
9
6
8
7
1.468
(37.2)
1
2
4
3
5
219DXBP
(4P-NO + 2P-NC )
1
7
8
0.10 Dia. x .435 (2.54 x 11)
Typical of all Pin Dimensions
14
PAGE 33
WEBSITE: www.magnecraft.com - EMAIL:info@magnecraft.com - FAX ON DEMAND 1-800/891-2957 - DOCUMENT 100
