CPD-E200E
The components identified by mark
are critical for safety.
¡
Replace only with part number specified.
(d)
REF.NO. PART NO.
DESCRIPTION
REMARK
REF.NO. PART NO.
DESCRIPTION
REMARK
D921 8-719-073-01 DIODE MA111-(K8).S0
JR007 1-216-295-91 SHORT
0
D922 1-216-051-00 RES,CHIP
D923 1-216-295-91 SHORT
D924 8-719-073-01 DIODE MA111-(K8).S0
D925 8-719-073-01 DIODE MA111-(K8).S0
1.2K
0
5% 1/10W
JR008 1-216-296-91 SHORT
JR009 1-216-295-91 SHORT
JR010 1-216-296-91 SHORT
JR011 1-216-296-91 SHORT
JR012 1-216-295-91 SHORT
0
0
0
0
0
D926 8-719-073-01 DIODE MA111-(K8).S0
D927 8-719-073-01 DIODE MA111-(K8).S0
D928 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D929 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D930 8-719-047-98 ZENER DIODE HZU5.6B2TRF
JR013 1-216-295-91 SHORT
JR014 1-216-296-91 SHORT
JR015 1-216-295-91 SHORT
JR016 1-216-295-91 SHORT
JR017 1-216-295-91 SHORT
0
0
0
0
0
D931 8-719-109-89 ZENER DIODE RD5.6ESB2
D932 8-719-109-89 ZENER DIODE RD5.6ESB2
D933 8-719-109-89 ZENER DIODE RD5.6ESB2
D934 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D935 8-719-109-85 ZENER DIODE RD5.1ESB2
JR018 1-216-295-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
JR022 1-216-295-91 SHORT
0
0
0
0
0
D936 8-719-109-89 ZENER DIODE RD5.6ESB2
D937 8-719-109-89 ZENER DIODE RD5.6ESB2
JR023 1-216-295-91 SHORT
JR024 1-216-296-91 SHORT
JR025 1-216-296-91 SHORT
JR027 1-216-296-91 SHORT
JR028 1-216-296-91 SHORT
0
0
0
0
0
<FUSE>
F601 ¡ 1-576-231-11 FUSE (H.B.C.) (4A/250V)
1-533-223-11 CLIP, FUSE ; F601
JR029 1-216-295-91 SHORT
JR030 1-216-295-91 SHORT
JR032 1-216-296-91 SHORT
JR033 1-216-296-91 SHORT
JR034 1-216-295-91 SHORT
0
0
0
0
0
<FERRITE BEAD>
FB502 1-412-473-51 FERRITE
FB504 1-412-911-11 FERRITE
FB506 1-412-911-11 FERRITE
FB904 1-543-961-22 FERRITE
0.45UH
JR038 1-216-296-91 SHORT
JR604 1-216-295-91 SHORT
JR606 1-216-295-91 SHORT
0
0
0
<IC>
<COIL>
IC401 8-759-339-59 IC TDA8177
IC501¡8-759-570-29 IC uPC6757CS
IC502 8-759-803-42 IC LA6500-FA
IC503 8-759-803-42 IC LA6500-FA
IC601¡8-759-594-75 IC TEA1504/N2
L501 1-406-663-21 INDUCTOR 47UH
L502 1-406-663-21 INDUCTOR 47UH
L503 1-411-594-41 INDUCTOR 5mH
L505 1-412-552-11 INDUCTOR 2.2mH
L506 1-412-548-31 INDUCTOR 820UH
IC602 8-759-592-79 IC BA00AST-V5
IC603¡8-749-016-35 IC TLP621D4-Y-LF2T
IC604 8-759-586-17 IC TL1431CZ-AP
IC605 8-759-637-83 IC PQ12RD8S
IC607¡8-759-450-47 IC BA05T
L507 1-414-856-11 INDUCTOR 10UH
L508 1-419-198-21 COIL, HORIZONTAL LINEARITY
L509 1-419-198-21 COIL, HORIZONTAL LINEARITY
L510 1-416-367-11 COIL, HORIZONTAL CENTER
L511 1-414-187-11 INDUCTOR 47UH
IC608 8-759-231-53 IC TA7805S
IC701 8-759-595-52 IC CXA8070AP
IC702 8-749-015-00 IC STK391-110
IC703 8-759-822-38 IC LA6510
IC901¡8-759-596-69 IC CXD9528S
L513 1-414-856-11 INDUCTOR 10UH
L602 1-412-529-11 INDUCTOR 22UH
L603 1-412-537-31 INDUCTOR 100UH
L604 1-406-665-11 INDUCTOR 100UH
L606 1-406-665-11 INDUCTOR 100UH
IC902 8-759-594-40 IC CXA8071CP
IC904 8-759-352-91 IC PST9143NL
IC905 8-759-527-76 IC M24C08-MN6T
L652 1-419-177-11 INDUCTOR
<FILTER>
<CHIP CONDUCTOR>
LF602¡1-429-180-11 TRANSFORMER, LINE FILTER
JR001 1-216-296-91 SHORT
JR003 1-216-295-91 SHORT
JR004 1-216-295-91 SHORT
JR006 1-216-295-91 SHORT
0
0
0
0
7-6
ETC [ ETC ]
