CM2841
150mA CMOS LDO WITH EN & PG
ORDERING INFORMATION
Part Number
Output Voltage
Temperature Range
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
-40℃ ~ +85℃
Package
SOT-23-5
SOT-23-5
SOT-23-5
SOT-23-5
SOT-23-5
SOT-23-5
CM2841ACIM25
CM2841ABIM25
CM2841AIM25
1.2V
1.3V
1.5V
1.2V
1.3V
1.5V
CM2841GACIM25
CM2841GABIM25
CM2841GAIM25
Note: For other pre-set output voltage, please contact Champion Sales office.
ABSOLUTE MAXIMUM RATINGS
OPERATING RATINGS
Input Voltage …………….……………………………. +7V
Ambient Temperature Range (TA) ……... -40℃ to +85℃
Junction Temperature Range …..…... -40℃ to +125℃
Output Current …………………….……
PD / (VIN - Vo)
Output Voltage …………………… GND-0.3V to VIN+0.3V
ESD Classification ………………………………………… B
THERMAL INFORMATION
Parameter
Maximum
Unit
℃/W
mW
SOT-23-5
SOT-23-5
160
250
Thermal Resistance (Θjc)
Internal Power Dissipation (PD)
(ΔT = 100℃)
Maximum Junction Temperature
Maximum Lead Temperature (10 Sec)
150
300
℃
℃
*With Junction sink capable of twice times ofΘjc
Caution: Stress above the listed absolute rating may cause permanent damage to the device.
2004/05/14 Rev. 1.3
Champion Microelectronic Corporation
Page 3
