Platform Cable USB II
iMPACT Cable Status Bar
A status bar on the bottom edge of the iMPACT GUI (Figure 7) provides information about cable operating conditions. For
example, if the host port is USB 2.0, Platform Cable USB II connects at Hi-Speed and the status bar shows usb-hs. If the
host port is USB 1.1, Platform Cable USB II connects at full-speed, and the status bar shows usb-fs. Finally, the status bar
displays the active cable and TCK_CCLK_SCK frequency.
X-Ref Target - Figure 7
DS593_07_021908
Figure 7: iMPACT (10.1) Cable Status Bar
Status Indicator
Platform Cable USB II uses a tri-color status LED to indicate the presence of target voltage and to indicate that a cable
firmware update is in progress (Figure 8).
When the cable is connected (using a ribbon cable, or flying leads) to a mating connector on the target system, the status
LED is illuminated as a function of the voltage present on pin 2 (V
). Users must design their system hardware with pin 2
REF
attached to a voltage plane suppling the JTAG, SPI, or Slave Serial pins on the target device(s). Some devices have
separate power pins for this purpose (V ), while others have a common supply for both V and the JTAG pins (TCK,
AUX
CCIO
TMS, TDI, and TDO). Refer to the target device data sheet for details on JTAG, Slave Serial or SPI pins.
The status LED is amber when any one or more of the following conditions exist:
The cable is not connected to a target system
The target system is not powered
The voltage on the V
pin is +1.3V.
REF
The status LED is green when all of the following conditions exist:
The cable is connected to a target system
The target system is powered
The voltage on the V
pin is +1.5V.
REF
Note: There is 200 mV of hysteresis in the VREF detection circuit. If VREF drops below 1.3V, the status LED turns amber and does not
turn green until VREF is raised above 1.5V.
The status LED is red whenever a cable firmware update is in progress.
DS593 (v1.2.1) March 17, 2011
www.xilinx.com
9
