QPRO High-Reliability QML Certified and Radiation Hardened Products for Aerospace and Defense
Unmatched
Product
Offering
The QPRO family provides a wide variety of devices, delivering the industry’s fastest and
biggest devices. The Virtex members of the QPRO family offers FPGAs with densities greater
than 1,000,000 system gates, and even larger devices planned for the future. This broad range
of devices is available in a wide variety of speed and package options. Both military
temperature and full QML/SMD versions are available as standard off-the-shelf products.
Select software cores, such as complete PowerPC peripherals, is also available.
Products for
Space
Applications
Xilinx offers the industry’s only radiation hardened reconfigurable FPGAs for satellite and
space. These devices are manufactured using an epitaxial wafer process, and have
guaranteed total dose, latch up immunity, and low soft upset rates. These products allow for the
ultimate in design and mission flexibility in a cost-effective manner.
QML
Being certified to MIL-PRF-38535 QML complemented by ISO-9000 certification results in an
overall product quality platform that makes Xilinx a world-class supplier of programmable logic
devices. Designers can confidently design with Xilinx for High-Reliability systems with the
knowledge they are getting unsurpassed quality and reliability, and long-term commitment to
the aerospace and defense market.
Certification
Part of Overall
Quality Platform
Commitment to
the Aerospace
and Defense
Market
Xilinx understands that our customers need to be able to count on their suppliers to be around
for the long-term. Xilinx is committed to the long-term support of the aerospace and defense
market, and we are continually expanding our product portfolio. Because our focus is in the
form of a vertical market concept, we are able to provide emphasis on all of our customer’s
product requirements.
Software and
Core Support
for Xilinx QPRO
High-Reliability
Products
Component Selection
The Alliance™ and Foundation™ Series Xilinx core implementation software tool suites do not
differentiate between Commercial, Industrial, and Military grade components. From the
perspective of the implementation tools these are identical devices with identical architectures
and available programming features. Therefore, there is no designation for QPRO or Radiation-
Hardened devices in the available device selection menus. However, the High-Reliability
product offering does typically include extended package selections to include available
ceramic packages.
To select a Hi-Rel device for implementation the user should specify the commercial equivalent
along with the specific package selection. Table 2 shows an example of Hi-Rel components
and the corresponding device selections that should be specified in the software.
Table 2: Hi-Rel Device Selections
Target Device
XQVR1000 CG560-4
XQV300 CB228-4M
XQ4085XL HQ240-1N
XQR4062XL CB228-3
Device Selection
XCV1000 CG560-4
XCV300 CB228-4
(1)
XC4085XLA HQ240-1
XC4062XL CB228-3
Notes:
1. The XQ4085XL is the only XQ4000XL series device that
uses an XLA rather than XL designation.
