Gas DischarGe Tubes
2 Electrode Series
Part Numbering System
Exampleꢀpartꢀnumber:
WPGT - 2R 800 B
8
L
C
TA
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(1)
(2)
World Products Gas Discharge Tubes
Series Code
2RM = 2 Electrode Mini Series
2R = 2 Electrode Standard Series and High Voltage Series
2N = 2 Electrode High Current Series
2T = 2 Electrode Switching Type
20B = 2 Electrode Extremely High Current Series
AE = 2 Electrode Standard, High Current, Ultra High Current & Screw Lead Series)
(3)
DC Breakdown Voltage
(Please reference specification to determine available voltage options for each series.)
70 = 70V
600 = 600V
75 = 75V
700 = 700V
90 = 90V
800 = 800V
120 = 120V
130 = 130V
145 = 145V
150 = 150V
180 = 180V
230 = 230V
250 = 250V
300 = 300V
350 = 350V
400 = 400V
420 = 420V
470 = 470V
600S = 600V
800S = 800V
1000 = 1000V
1200 = 1200V
1400 = 1400V
1600 = 1600V
2000 = 2000V
2500 = 2500V
2700 = 2700V
3000 = 3000V
3500 = 3500V
3600 = 3600V
4000 = 4000V
4500 = 4500V
5000 = 5000V
6000 = 6000V
(4)
(5)
Diameter (“D” Dimension)
Aꢀ=ꢀ5.5mmꢀ-ꢀ2RMꢀSeriesꢀOnly
B = 8mm
D = 11ꢀ8mm for AE Series
Nilꢀ=ꢀForꢀ20BꢀSeries
(7)
Low Capacitance
(Only applicable for 2R & 2N, 70V – 145V)
C = Low capacitance of 0ꢀ8pf
(8)
Taping Specifications
TA = Taped (Ammo Box)
TR = Tape & Reel
Length (“T” Dimension)
6 = 6mm
8 = 8mm
10ꢀ=ꢀ10mmꢀ-ꢀHighꢀVoltageꢀSeriesꢀOnly
12 = 12mm
17 = 17mm
Nilꢀ=ꢀForꢀ20BꢀSeries
(6)
Lead Type
B = No Leads
Nil = No Leads for 20B Series
L = Axial lead (0ꢀ8mm lead diameter)
L1 = Axial lead (1ꢀ0mm lead diameter)
A1 = Radial lead (0ꢀ8mm lead diameter)
B1 = Radial lead (1ꢀ0mm lead diameter)
C1ꢀ=ꢀRadialꢀleadꢀClip-inꢀstyleꢀ(1.0mmꢀleadꢀ
diameter)
D1ꢀ=ꢀRadialꢀLeadꢀClip-inꢀstyleꢀ(0.8mmꢀleadꢀ
diameter)
D4 = Radial Lead for 20B Series
D5 = Tab Lead for 20B Series
S = Screw Lead Type for AE Series
WORLD PRODUCTS INC. 19654 Eighth Street East, Sonoma, CA 95476 | Phone (707) 996-5201 | Fax (707) 996-3380 | www.worldproducts.com
Rev. 13.9
