W25Q20BW
3. PIN CONFIGURATION SOIC 150-MIL
Figure 1a. W25Q20BW Pin Assignments, 8-pin SOIC 150-mil (Package Code SN)
4. PAD CONFIGURATION WSON 6X5-MM, USON 2X3-MM
Figure 1b. W25Q20BW Pad Assignments, 8-pad WSON 6x5-mm, USON 2x3-mm (Package Code ZP & UX)
5. PIN DESCRIPTION SOIC 150-MIL, WSON 6X5-MM & USON 2X3-MM
PIN NO.
PIN NAME
/CS
I/O
I
FUNCTION
1
2
3
4
5
6
7
8
Chip Select Input
DO (IO1)
/WP (IO2)
GND
I/O
I/O
Data Output (Data Input Output 1)*1
Write Protect Input ( Data Input Output 2)*2
Ground
DI (IO0)
CLK
I/O
I
Data Input (Data Input Output 0)*1
Serial Clock Input
/HOLD (IO3)
VCC
I/O
Hold Input (Data Input Output 3)*2
Power Supply
*1 IO0 and IO1 are used for Standard and Dual SPI instructions
*2 IO0 – IO3 are used for Quad SPI instructions
- 6 -
