Housings
Housings
SEG-U/LPU
EG 6
Rated data
Reference voltage acc. to VDE 0110 1/89
Pollution severity
Overvoltage category
Current
Current-carrying capacity of bus contacts
Volume resistance of bus contacts
Printed circuit board dimensions
Power loss (when mounted in row)
Protection class
Flammability acc. to UL level
Upper temperature limit
Connection data
Screw connection solid
Screw connection stranded
Tightening torque range
Torque phase with electric screwdriver DMS 2
50 V
2
III
1A
32 V nach VDE 0110/1.89
2
III
1 A/δ
U
50
0
C
12 mΩ
100 x 120 x 1.8 mm
1.5 W
IP 20
V -2
100 °C
0.5...4 mm
2
0.5...2.5 mm
2
0.5 Nm
1
IP 00
V-2
100 °C
Ordering data
Housing frame
End plate
Combi foot, latchable
Assembly plate
Clamping yoke unit, right
Clamping yoke unit, left
Intermediate plate
Connection spigot
Connection tab 0.8 x 6.3 mm
Connection tab 2 x 0.8 x 2.8 mm
Tab / solder lug 0.8 x 2.8 mm
Tab / solder lug 0.8 x 4.8 mm
Printed circuit board, copper-coated
Printed circuit board 2.54 pitch
Dimensions
See page
Type
Housing SEG/U
Cover plate
Cat. No.
8007870000
8066100000
Qty.
–
–
Type
EG 6 (incl. front plate)
Cat. No.
8095840000
307
307
300
