Data sheet | Item number: 756-1102/060-100
www.wago.com/756-1102/060-100
Insulation resistance
Conductor resistance
> 2500 MΩ/km
max. 55 Ω/km; Loop resistance: max. 110 Ω/km
Mechanical data
Bending radius
> 10 x cable Ø (flexible use); > 5 x cable Ø in drag chain (fixed
installation)
Bending cycles
Drag chain suitability
Sheathed cable diameter
Type code
1 Mio.
yes
7.3 … 7.9 mm
LI02YS-(ST)CB11Y 1X(2X0.34SQMM)
Shield
Shielding braid, (approx. 5.90 mm Ø), tinned CU-ETP1, coverage 85
% ± 5 %
Conductor design
Conductor insulation
Housing material
Tightening torque
Weight
Bare copper wire (19 x 0.15 mm)
PE (halogen-free); Filler: PP yarn
TPU/TPU, black (~ RAL 9005)
1 Nm
700 g
violet
Color
Environmental requirements
Surrounding air (operating) temperature (dynamic)
Surrounding air (operating) temperature (static)
Protection type
-25 … +60 °C
-50 … +60 °C
IP67
Pollution degree (5)
3/2 per IEC 60664-1
Commercial data
PU (SPU)
1 Stück
Packaging type
Country of origin
GTIN
box
DE
4045454521578
85444290900
Customs tariff number
Approvals / Certificates
UL-Approvals
Certificate
Logo
Approval
Additional Approval Text
UL 2238
name
UL
E519602
Underwriters Laboratories Inc.
Subject to changes. Please also observe the further product documentation!
