SVRTR2800D Series
5.0 MECHANICAL OUTLINES AND PINOUT (CONTINUED)
Flanged Package Option:
2.890in 73.41mm MAX
2.550in 64.77
0.260in 0.025 6.60mm 0.64
0.405in 10.29mm MAX
2.125in 53.98mm MAX
R0.160in
4.06mm
PIN 1
0.162in
4.11mm
+
0.000
0.005
0
0.13
0.060in
1.52mm
-
-
0.155in 3.94mm
0in 0mm
BASEPLATE
SURFACE
1
2
9
3
8
4
7
5
6
0.400in 10.16mm
0.800in 20.32mm
10
8X SEAL
0.124in 0.003
10X PIN
0.040in 0.003
3.15mm 0.08
1.02mm 0.08
1. Tolerances are +0.005” unless otherwise stated
2. Case temperature is measured on the center of the baseplate surface
3. Mounting holes are not threaded. Recommended fastener is 6-32
4. Materials: Case (Steel, gold over nickel plated); Cover (Kovar, nickel plated); Pin (Copper-cored alloy 52, gold over nickel plated); Pin Seals (Ceramic)
Pin Function
Pin Function
Pin Function
Pin Function
1
2
3
28VIN
4
5
6
OUTCOM
7
8
9
CASE
CASE
SYNC
10
INCOM
INH
-VOUT
+VOUT
CASE
