TDA7266
LINEAR INTEGRATED CIRCUIT
ꢀ
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
VCC
RATINGS
20
UNIT
V
Supply Voltage
Output Peak Current (internally limited)
Power Dissipation (TC =70℃)
Junction Temperature
IOUT
2
A
PD
33
W
℃
℃
℃
TJ
+125
Operating Temperature
TOPR
TSTG
0 ~ +70
-40 ~ +150
Storage Temperature
Note: 1.Absolute maximum ratings are those values beyond which the device which the device could be permanently
damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2.The device is guaranteed to meet performance specification within 0℃~+70℃ operating temperature range
and assured by design from -20℃~+85℃, characteristic and correlation with static process control.
ꢀ
THERMAL DATA
PARAMETER
Thermal Resistance Junction to Case
SYMBOL
θJC
RATINGS
1.4
UNIT
℃/W
ꢀ
ELECTRICAL CHARACTERISTICS(VCC=11V, RL =8Ω, f=1kHz, Ta=25℃, unless otherwise specified)
PARAMETER
SYMBOL
VCC
TEST CONDITIONS
MIN
3
TYP
11
MAX
18
UNIT
V
Supply Range
Output Offset Voltage
Total Output Noise Voltage
Total Quiescent Current
Input Resistance
VO(OFF
)
120
mV
µV
mA
kΩ
W
eN
A curve, f=20Hz ~ 20kHz
150
48
IQ
65
RIN
25
30
Output Power
POUT THD=10%
6.3
7
POUT=1W
THD
0.05
0.2
1
%
Total Harmonic Distortion
P
OUT=0.1~2W, f=100Hz~15kHz
%
Crosstalk
CT
Gv
46
25
60
26
dB
dB
dB
dB
℃
Closed Loop Voltage Gain
Voltage Gain Matching
Supply Voltage Rejection
Thermal Threshold
MUTE FUNCTION
27
△Gv
0.5
SVR f=100Hz, VR=0.5V
Tt
40
56
150
for VCC>6.4V, VOUT= -30dB
2.3
2.9
4.1
V
V
Mute Threshold
VMTHD
AMUTE
VCC/2-1.0 VCC/2-0.75 VCC/2-0.5
for VCC<6.4V, VOUT= -30dB
Mute Attenuation
60
80
dB
STAND BY FUNCTION
STAND-BY Threshold
STAND-BY Current V6=GND
VTST-BY
IST-BY
0.8
1.3
1.8
V
100
µA
UNISONIC TECHNOLOGIES CO., LTD
3 of 7
QW-R107-037,A
