7 Package Dimensions
Package: FBGA 256 balls, 1.0mm pitch, size 17mm x 17mm,
industrial temperature range 0°C . . . 85°C, RoHS compliant.
Figure 17: FBGA256 Package Outline
FBGA256 Package Dimensions in mm
min.
-
typ.
max.
2.20
-
A
-
A1 0.30
-
A2
A3
D
-
-
1.80
0.70 REF
17.00 BSC
17.00 BSC
0.60
E
b
0.50
0.70
e
1.00 BSC
JEDEC MS-034, Variation: AAF-1
Table 12: Package Outline Dimensions
