TLCS-870 Series (1/3)
غ
Software Products
Language Tool
Debugger
C/C-Like Compiler & Assembler Set
SW87YN0-ZCJ: 1 license (Japanese edition)
SW87YN0-ZCE: 1 license (English edition)
SW87YN3-ZCJ: 10 licenses (Japanese edition)
SW87YN3-ZCE: 10 licenses (English edition)
SW87DN9-ZCK: 1 license (Japanese edition)
SW87DN9-ZCF: 1 license (English edition)
SW87DN3-ZCK: 10 licenses (Japanese edition)
SW87DN3-ZCF: 10 licenses (English edition)
غ
Hardware Products
RTE870 model 10 In-Circuit Emulation System
Target MCU
In-Circuit Emulator
Accessory
MCU Mount Adapter
/IC Socket
Part Number
Package
Controller
Emulation Pod
MCU Probe
Package Converter
TMP87C405AMG
TMP87C807UG
TMP87C408LNG
TMP87C408NG
TMP87C808LNG
TMP87C808NG
TMP87P808LNG
TMP87P808NG
TMP87C408LMG
TMP87C408MG
TMP87C808LMG
TMP87C808MG
TMP87P808LMG
TMP87P808MG
TMP87C408DMG
TMP87C409BNG
TMP87C809BNG
TMP87P809NG
TMP87C409BMG
TMP87C809BMG
TMP87P809MG
TMP87C814FG
TMP87CH14FG
TMP87CK14FG
TMP87CM14FG
TMP87PM14FG
TMP87C814NG
TMP87CH14NG
TMP87CK14NG
TMP87CM14NG
TMP87PM14NG
TMP87CH21CDFG
TMP87CM21CDFG
TMP87CP21CDFG
TMP87PP21DFG
TMP87CH21CFG
TMP87CM21CFG
TMP87CP21CFG
TMP87PP21FG
TMP87CM23AFG
TMP87CP23FG
TMP87PP23FG
TMP87CH29UG
TMP87CK29UG
TMP87CM29UG
SOP28
BM87C408M0A
BM87CH47U0B
##
##
PN100003
PN120011
*1
*1
AS-DIP.6-028-SO08-1 *1, *2
QFP44 (10 x 10)
PN210020A
SDIP28
SOP28
PN200004
BM87C408M0A
##
PN100003
*1
AS-DIP.6-028-SO08-1 *1, *2
SSOP30
SDIP28
PN200007
IC253-030-0002-B *3
PN200004
*1
BM87C809N0A
##
PN100003
*1
SOP28
AS-DIP.6-028-SO08-1 *2
BM1022R0B
##
QFP64 (14 x 20)
PN120007
PN210011A
BM87CM14N0A
##
PN110008
*1
SDIP64
LQFP80 (12 x 12)
QFP80 (14 x 20)
PN120006A
PN120004
PN210008
PN210002
BM87CP23F0B
##
QFP100 (14 x 20)
LQFP64 (10 x 10)
PN120005
PN120022
*1
*1
PN210005A
PN210033
BM87CM29U0B
##
٨
The TLCS-870 Series software products run in the following environments:
C/C-Like Compiler & Assembler Set: Japanese or English Microsoft® Windows® 98 and Microsoft® Windows NT®4.0.
Debugger: Japanese or English Microsoft® Windows® 2000 and Microsoft® Windows® XP.
Microsoft, Windows and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
٨
One QFP adapter and one pin protector are supplied with an MCU probe or a package converter whose name begins with “PN12”.
When you purchase additional QFP adaptors or pin protectors, check their part numbers in the section “Spare Parts from Toshiba.”
٨
For the supported Programming tools, see the section “Programming Tools”.
٨
Contact the Toshiba sales representative for information about RoHS compliance before you purchase any components.
##: Contact your local Toshiba sales representative before ordering products.
*1: These are spare parts. One spare part is supplied with each emulation pod.
*2: The package converters (DIP28 SOP28) whose part numbers begin with AS are Emulation Technology’s products.
*3: One IC socket is supplied with the package converter. The IC socket is Yamaichi Electronics’ product.
ꢁꢀ
