TK111xxM
TK111xxMIL ELECTRICAL CHARACTERISTICS TABLE 2
Test Conditions: VIN = VOUT(TYP) + 1 V, IOUT = 30 mA, unless otherwise specified.
Room Temp. Range (TA = 25 °C)
Full Temp. Range (TA = -40 to +85 °C)
Output
Voltage
Voltage
Code
VOUT(MIN)
VOUT(MAX)
VOUT(MIN)
VOUT(MAX)
2.4 V
2.5 V
2.7 V
2.8 V
2.9 V
3.0 V
3.1 V
3.2 V
3.3 V
3.4 V
3.5 V
3.6 V
3.7 V
3.8 V
3.9 V
4.0 V
4.1 V
4.2 V
4.3 V
4.4 V
4.5 V
4.6 V
4.7 V
4.8 V
4.9 V
5.0 V
24
25
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
2.340 V
2.440 V
2.640 V
2.740 V
2.840 V
2.940 V
3.038 V
3.136 V
3.234 V
3.332 V
3.430 V
3.528 V
3.626 V
3.724 V
3.822 V
3.920 V
4.018 V
4.116 V
4.214 V
4.312 V
4.410 V
4.598 V
4.696 V
4.794 V
4.892 V
4.900 V
2.460 V
2.560 V
2.760 V
2.860 V
2.960 V
3.060 V
3.162 V
3.264 V
3.366 V
3.468 V
3.570 V
3.672 V
3.774 V
3.876 V
3.988 V
4.080 V
4.182 V
4.284 V
4.366 V
4.488 V
4.590 V
4.692 V
4.794 V
4.896 V
4.998 V
5.100 V
2.305 V
2.405 V
2.605 V
2.705 V
2.805 V
2.905 V
3.007 V
3.104 V
3.201 V
3.298 V
3.395 V
3.492 V
3.589 V
3.686 V
3.783 V
3.880 V
3.977 V
4.074 V
4.171 V
4.268 V
4.365 V
4.462 V
4.559 V
4.656 V
4.753 V
4.850 V
2.495 V
2.595 V
2.795 V
2.895 V
2.995 V
3.095 V
3.193 V
3.296 V
3.400 V
3.502 V
3.605 V
3.708 V
3.811 V
3.914 V
4.017 V
4.120 V
4.223 V
4.326 V
4.429 V
4.532 V
4.635 V
4.738 V
4.841 V
4.944 V
5.047 V
5.150 V
