THEORY OF OPERATION
Interleaving
One of the main benefits from the 180° interleaving of phases is significant reductions in the high-frequency
ripple components of both the input current and the current into the output capacitor of the PFC pre-regulator.
Compared to that of a single-phase PFC stage of equal power, the reduced ripple on the input current eases the
burden of filtering conducted-EMI noise and helps reduce the EMI filter and CIN sizes. Additionally, reduced
high-frequency ripple current into the PFC output capacitor, COUT, helps to reduce its size and cost. Furthermore,
with reduced ripple and average current in each phase, the boost inductor size can be smaller than in a
single-phase design [1].
Ripple current reduction due to interleaving is often referred to as "ripple cancellation", but strictly speaking, the
peak-to-peak ripple is completely cancelled only at 50% duty-cycle in a 2-phase system. At duty-cycles other
than 50%, ripple reduction occurs in the form of partial cancellation due to the superposition of the individual
phase currents. Nevertheless, compared to the ripple currents of an equivalent single-phase PFC pre-regulator,
those of a 2-phase interleaved design are extraordinarily smaller [1]. Independent of ripple cancellation, the
frequency of the interleaved ripple, at both the input and output, is 2 x fPWM
.
On the input, 180° interleaving reduces the peak-to-peak ripple amplitude to 1/2 or less of the ripple amplitude of
the equivalent single-phase current.
On the output, 180° interleaving reduces the rms value of the PFC-generated ripple current in the output
capacitor by a factor of slightly more than √2, for PWM duty-cycles > 50%.
This can be seen in the following derivations, adapting the method by Erickson [2].
In a single-phase PFC pre-regulator, the total rms capacitor current contributed by the PFC stage at all
duty-cycles can be shown to be approximated by:
æ
ö
æ
ç
è
ö
÷
ø
æ IO ö
÷
16VO
3pVM
iCRMS1j
=
-1h2
ç
÷
ç
ç
÷
h
è
ø
è
ø
(1)
In a dual-phase interleaved PFC pre-regulator, the total rms capacitor current contributed by the PFC stage for D
> 50% can be shown to be approximated by:
æ
ö
æ
ç
è
ö
÷
ø
æ IO ö
÷
16VO
iCRMS 2j
=
-1h2
ç
÷
ç
ç
÷
h
6pVM
è
ø
è
ø
(2)
In these equations, IO = average PFC output load current, VO = average PFC output voltage, VM = peak of the
input ac-line voltage, and η = efficiency of the PFC stage at these conditions. It can be seen that the quantity
under the radical for iCrms2φ is slightly smaller than 1/2 of that under the radical for iCrms1φ. The rms currents
shown contain both the low-frequency and the high-frequency components of the PFC output current.
Interleaving reduces the high-frequency component, but not the low-frequency component.
