Drive Current and Power Dissipation
The UCC27523/4/5/6 family of drivers are capable of delivering 5-A of current to a MOSFET gate for a period of
several hundred nanoseconds at VDD = 12 V. High peak current is required to turn the device ON quickly. Then,
to turn the device OFF, the driver is required to sink a similar amount of current to ground. This repeats at the
operating frequency of the power device. The power dissipated in the gate driver device package depends on the
following factors:
•
Gate charge required of the power MOSFET (usually a function of the drive voltage VGS, which is very close
to input bias supply voltage VDD due to low VOH drop-out)
•
•
Switching frequency
Use of external gate resistors
Since UCC2752x features very low quiescent currents and internal logic to eliminate any shoot-through in the
output driver stage, their effect on the power dissipation within the gate driver can be safely assumed to be
negligible.
When a driver device is tested with a discrete, capacitive load it is a fairly simple matter to calculate the power
that is required from the bias supply. The energy that must be transferred from the bias supply to charge the
capacitor is given by:
1
2
EG
=
CLOADVDD
2
(1)
where is load capacitor and is bias voltage feeding the driver.
There is an equal amount of energy dissipated when the capacitor is charged. This leads to a total power loss
given by the following:
2
LOAD DD SW
P
= C
V
f
G
(2)
where fSW is the switching frequency.
With VDD = 12 V, CLOAD = 10 nF and ƒSW = 300 kHz the power loss can be calculated as:
2
= 10nF´12V ´300kHz = 0.432W
P
G
(3)
