表 7-10. Frame-Byte Description
BYTE NAME
SYNC
LENGTH (byte)
DESCRIPTION
Synchronization byte from master
Device address bit, r/w, broadcast, burst mode
Register address
1
DEV_ADDR
REG_ADDR
DATA_N
1
1
Variable (1, 4, 16, 24)
N-th byte data content
Cyclic redundancy check (CRC) for DEV_ADDR, REG_ADDR and all
DATA bytes
CRC
1
1
STATUS
Acknowledgment (Return FLAG_ERR register value)
7.5.1.2 UART Interface Address Setting
Each FlexWire bus supports maximum 16 slave devices. The TPS929160-Q1 has three pinouts including
ADDR3, ADDR2, ADDR1, and ADDR0 for slave address configuration. There are additional 4-bit EEPROM
register to program the slave address of the TPS929160-Q1. The register INTADDR sets the device slave
address by either address pins setup or internal EEPROM register code.
If INTADDR is 1, the device uses the binary code in register DEVADDR[3:0] as slave address as shown in the
below table.
If INTADDR is 0, the device uses external inputs on ADDR3, ADDR2, ADDR1 and ADDR0 as shown in 表 7-11
and ignore DEVADDR[3:0] code.
The address 0h to Fh can be used as slave address for up to 16 pieces of TPS929160-Q1 in the same
FlexWire bus. Do not have two TPS929160-Q1 sharing the same slave address either setting by internal register
DEVADDR or address pins configuration on ADDR3, ADDR2, ADDR1 and ADDR0.
The default value for DEVADDR[3:0] is 0h.
表 7-11. Device Address Setting
INTERNAL ADDRESS SETTING
BIT2 BIT1
DEVADDR[3] DEVADDR[2] DEVADDR[1] DEVADDR[0]
EXTERNAL ADDRESS SETTING
Address(HEX)
BIT3
BIT0
BIT3
BIT2
BIT1
BIT0
ADDR3
ADDR2
ADDR1
ADDR0
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
