TMS570LS3137
SPNS162.–SEPTEMBER 2011
www.ti.com
The figure below illustrates the numbering and symbol nomenclature for the TMS570LS3137 .
Full Part #
TMS
TMX
570
570
LS 31
31
3
3
7
7
A
A
ZWT
ZWT
Q
Q
Q1
Q1
R
R
Orderable Part #
Prefix: TM
TMS = Fully Qualified
TMP = Prototype
TMX = Samples
Core Technology:
570 = Cortex R4F
Architecture:
LS = Dual CPUs in Lockstep
(not included in orderable part #)
Flash Memory Size:
31 = 3MB
RAM MemorySize:
3 = 256kB
Peripheral Set:
7 = FlexRay, Ethernet
Die Revision:
Blank = Initial Die
A = 1st Die Revision
Package Type:
ZWT = 337 BGA Package
PGE = 144 Pin Package
Temperature Range:
Q = -40...+125oC
Quality Designator:
Q1 = Automotive
Shipping Options:
R = Tape and Reel
Figure 1-1. TMS570LS3137 Device Numbering Conventions
1.1.2 Orderable Part Numbers
Table 1-1. Orderable Part Numbers
Orderable Part #
Part #
Flash
3MB
3MB
RAM
256kB
256kB
EMAC
10/100
10/100
FlexRay
2ch
TMX5703137APGEQQ1
TMX5703137AZWTQQ1
TMS570LS3137
TMS570LS3137
2ch
8
