SPRS080F − MARCH 1999 − REVISED OCTOBER 2008
mechanical data
The following packaging information reflects the most current released data available for the designated
device(s). This data is subject to change without notice and without revision of this document.
package thermal resistance characteristics
Table 15 provides the estimated thermal resistance characteristics for the recommended package types used
on the device.
Table 15. Thermal Resistance Characteristics
PARAMETER
PGE PACKAGE
GGU PACKAGE
UNIT
°C/W
°C/W
R
R
56
5
38
5
ΘJA
ΘJC
76
