PACKAGE MATERIALS INFORMATION
www.ti.com
24-Jun-2023
TRAY
L - Outer tray length without tabs
KO -
Outer
tray
height
W -
Outer
tray
width
Text
P1 - Tray unit pocket pitch
CW - Measurement for tray edge (Y direction) to corner pocket center
CL - Measurement for tray edge (X direction) to corner pocket center
Chamfer on Tray corner indicates Pin 1 orientation of packed units.
*All dimensions are nominal
Device
Package Package Pins SPQ Unit array
Max
matrix temperature
(°C)
L (mm)
W
K0
P1
CL
CW
Name
Type
(mm) (µm) (mm) (mm) (mm)
TMS320F280200PTT
TMS320F28020PTT
TMS320F28021PTS
TMS320F28021PTT
TMS320F28022PTQ
TMS320F28022PTS
TMS320F28022PTT
TMS320F28023PTQ
TMS320F28023PTS
TMS320F28023PTT
TMS320F28026FPTQ
TMS320F28026FPTT
TMS320F28026PTQ
TMS320F28026PTS
TMS320F28026PTT
TMS320F28027FPTQ
TMS320F28027FPTT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
PT
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
LQFP
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
48
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
10 x 25
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
150
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
315 135.9 7620 12.2
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
11.1 11.25
Pack Materials-Page 4
