TMS320C6678
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS691D—April 2013
www.ti.com
1 Features
•
Eight TMS320C66x™ DSP Core Subsystems (C66x
CorePacs), Each with
•
Peripherals
– Four Lanes of SRIO 2.1
– 1.0 GHz or 1.25 GHz C66x Fixed/Floating-Point
›
1.24/2.5/3.125/5 GBaud Operation Supported
Per Lane
CPU Core
›
›
40 GMAC/Core for Fixed Point @ 1.25 GHz
20 GFLOP/Core for Floating Point @ 1.25 GHz
›
›
Supports Direct I/O, Message Passing
Supports Four 1×, Two 2×, One 4×, and Two 1× +
One 2× Link Configurations
– Memory
›
›
›
32K Byte L1P Per Core
32K Byte L1D Per Core
512K Byte Local L2 Per Core
•
Multicore Shared Memory Controller (MSMC)
– 4096KB MSM SRAM Memory Shared by Eight DSP
C66x CorePacs
– Memory Protection Unit for Both MSM SRAM and
DDR3_EMIF
•
•
Multicore Navigator
– 8192 Multipurpose Hardware Queues with Queue
Manager
– Packet-Based DMA for Zero-Overhead Transfers
– 16-Bit EMIF
– Two Telecom Serial Ports (TSIP)
Network Coprocessor
– Packet Accelerator Enables Support for
›
›
Supports 1024 DS0s Per TSIP
Supports 2/4/8 Lanes at 32.768/16.384/8.192
Mbps Per Lane
›
›
›
Transport Plane IPsec, GTP-U, SCTP, PDCP
L2 User Plane PDCP (RoHC, Air Ciphering)
1-Gbps Wire-Speed Throughput at 1.5 MPackets
Per Second
– UART Interface
– I2C Interface
– 16 GPIO Pins
– Security Accelerator Engine Enables Support for
›
IPSec, SRTP, 3GPP, WiMAX Air Interface, and
SSL/TLS Security
– SPI Interface
›
ECB, CBC, CTR, F8, A5/3, CCM, GCM, HMAC,
CMAC, GMAC, AES, DES, 3DES, Kasumi, SNOW
3G, SHA-1, SHA-2 (256-bit Hash), MD5
– Semaphore Module
– Sixteen 64-Bit Timers
– Three On-Chip PLLs
›
Up to 2.8 Gbps Encryption Speed
•
•
Commercial Temperature:
– 0°C to 85°C
Extended Temperature:
– - 40°C to 100°C
