TAS5709
www.ti.com ........................................................................................................................................................................................... SLOS599–NOVEMBER 2008
VOLUME REGISTERS (0x07, 0x08, 0x09)
Step size is 0.5 dB.
Master volume
– 0x07 (default is mute)
– 0x08 (default is 0 dB)
– 0x09 (default is 0 dB)
Channel-1 volume
Channel-2 volume
Table 10. Volume Registers (0x07, 0x08, 0x09)
D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
FUNCTION
0
0
0
0
0
0
0
0
24 dB
(1)
0
0
1
1
0
0
0
0
0 dB (default for individual channel volume)
1
1
1
1
1
1
1
1
0
0
0
1
0
0
0
1
1
1
1
1
1
1
1
1
0
1
1
1
1
0
1
1
–78.5 dB
–79.0 dB
Values between 0xCF and 0xFE are Reserved
MUTE
(1) Default values are in bold.
Copyright © 2008, Texas Instruments Incorporated
Submit Documentation Feedback
43
Product Folder Link(s): TAS5709
