TAS5709
SLOS599–NOVEMBER 2008........................................................................................................................................................................................... www.ti.com
Table 2. Serial Control Interface Register Summary (continued)
NO. OF
BYTES
INITIALIZATION
VALUE
SUBADDRESS
REGISTER NAME
ch3 BQ[0]
CONTENTS
0x5E
20
u[31:26], b0[25:0]
u[31:26], b1[25:0]
u[31:26], b2[25:0]
u[31:26], a1[25:0]
u[31:26], a2[25:0]
u[31:26], b0[25:0]
u[31:26], b1[25:0]
u[31:26], b2[25:0]
u[31:26], a1[25:0]
u[31:26], a2[25:0]
Reserved(4)
0x0080 0000
0x0000 0000
0x0000 0000
0x0000 0000
0x0000 0000
0x0080 0000
0x0000 0000
0x0000 0000
0x0000 0000
0x0000 0000
0x0000 0000
0x0000 0036
0x5F
ch3 BQ[1]
20
0x60–0xF8
0XF9
4
4
Update Dev Address Reg
u[31:8],New Dev Id[7:0] (New Dev Id = 0X38 for
TAS5709)
0xFA–0xFF
4
Reserved(4)
0x0000 0000
(4) Reserved registers should not be accessed.
All DAP coefficients are 3.23 format unless specified otherwise.
