Appendix A
Table 4. Bill of Materials for TAS5624DDVEVM (continued)
Manu Part No.
Qty Ref Des
Vendor Part No.
Description
Vendor
Manu
UKZ1H470MPM
1
C72
493-3194
CAP ALUM ELEC KZ RADIAL 47UFD 50V
20% ROHS
Digi-Key
Nichicon
EEU-FC1H102
2
C12, C14
P10333-ND
CAP ALUM ELEC FC RADIAL 1000UFD 50V
20% ROHS
Digi-Key
Panasonic
RESISTORS
RMCF0402ZT0R00
ERJ-3GEY0R00V
ERJ-3GEYJ1R0V
ERJ-3GEYJ3R3V
2
1
1
8
R12, R13
R51
RMCF0402ZT0R00CT
ZERO OHM JUMPER SMT 0402 0 OHM
1/16W,5% ROHS
Digi-Key
Digi-Key
Digi-Key
Digi-Key
Stackpole
Electronics
P0.0GCT
RESISTOR SMD0603 0.0 OHM 5% THICK
FILM 1/10W ROHS
Panasonic
Panasonic
Panasonic
R50
P1.0GCT
RESISTOR SMD0603 1.0 OHMS 1% THICK
FILM 1/10W ROHS
R1, R7, R8,
R9, R10,
R11, R14,
R60
P3.3GCT
RESISTOR SMD0603 3.3 OHMS 5% 1/10W
ROHS
ERJ-3GEYJ470V
19 R27, R28,
R29, R30,
R31, R32,
R33, R34,
R35, R36,
R37, R38,
R39, R40,
R54, R55,
R56, R57,
R58
P47GCT
RESISTOR SMD0603 47 OHMS 5% 1/10W
ROHS
Digi-Key
Panasonic
CRCW0603100RFKEA
ERJ-3GEYJ471V
ERJ-3GEYJ472V
ERJ-3EKF1002V
3
2
4
R4, R5, R6
541-100HCT
P470GCT
RESISTOR SMD0603 100 OHM 1/10W 1%
ROHS
Digi-Key
Digi-Key
Digi-Key
Digi-Key
Vishay
R48, R49
RESISTOR SMD0603 470 OHMS 5% 1/10W
ROHS
Panasonic
Panasonic
Panasonic
R61, R62,
R63, R65
P4.7KGCT
P10.0KHCT
RESISTOR SMD0603 4.7K OHMS 5% 1/10W
ROHS
14 R20, R21,
R22, R23,
R24, R25,
R26, R41,
R42, R43,
R44, R45,
R46, R47
RESISTOR SMD0603 10.0K 1% THICK FILM
1/10W ROHS
RMCF0603FT15K0
RC0603FR-0718KL
RC0603FR-0730KL
ERJ-3GEYJ473V
1
1
1
1
R52
R53
R2
RMCF0603FT15K0CT
311-18.0KHRCT
311-30.0KHRCT
P47KGCT
RESISTOR SMD0603 15.0K OHMS 1% 1/10W Digi-Key
ROHS
Stackpole
Electronics
RESISTOR SMD0603 THICK FILM 18.0K
OHMS 1% 1/10W ROHS
Digi-Key
Digi-Key
Digi-Key
Yageo
RESISTOR SMD0603 THICK FILM 30.0K 1%
1/10W ROHS
Yageo
R3
RESISTOR SMD0603 47K OHMS 5% 1/10W
ROHS
Panasonic
INDUCTORS
MA5173-AE
4
L1, L2, L3, L4 MA5173-AE
SHIELDED POWER INDUCTOR 7uH 12A
ROHS
Coil Craft
Coil Craft
HEADERS
N2526-6002-RB
PBC02SAAN
PBC03SAAN
1
1
3
J1
MHC26K-ND
HEADER SHROUDED 100LS MALE GOLD
2X13 PINS ROHS
Digi-Key
Digi-Key
Digi-Key
3M
JP1
S1011E-02-ND
S1011E-03-ND
HEADER THRU MALE 2 PIN 100LS GOLD
ROHS
Sullins
Sullins
C, D, M3
HEADER THRU MALE 3 PIN 100LS GOLD
ROHS
TESTPOINTS AND SWITCHES
5003
1
1
ET2
S1
5003K
PC TESTPOINT, ORANGE, ROHS
Digi-Key
Digi-Key
Keystone
Electronics
G12AP-RO
360-1758
SWITCH THRU SPDT STRAIGHT ULTRA
MINIATURE ROHS
NKK
BINDING POSTS
5018-0
3
GND, LOUT-, 565-5018-0
ROUT-
BINDING POST, BLACK 60V 30A GOLD
ROHS
Mouser
Pomona
13
