PACKAGE MATERIALS INFORMATION
www.ti.com
7-Nov-2013
*All dimensions are nominal
Device
SN74LVC1G58DBVR
SN74LVC1G58DCKR
SN74LVC1G58DCKR
SN74LVC1G58DRLR
SN74LVC1G58DRLR
SN74LVC1G58DRY2
SN74LVC1G58DRYR
SN74LVC1G58DSF2
SN74LVC1G58DSFR
SN74LVC1G58YZPR
Package Type
SOT-23
SC70
SC70
SOT
SOT
SON
SON
SON
SON
DSBGA
Package Drawing
DBV
DCK
DCK
DRL
DRL
DRY
DRY
DSF
DSF
YZP
Pins
6
6
6
6
6
6
6
6
6
6
SPQ
3000
3000
3000
4000
4000
5000
5000
5000
5000
3000
Length (mm)
180.0
205.0
180.0
180.0
202.0
180.0
180.0
180.0
180.0
220.0
Width (mm)
180.0
200.0
180.0
180.0
201.0
180.0
180.0
180.0
180.0
220.0
Height (mm)
18.0
33.0
18.0
30.0
28.0
30.0
30.0
30.0
30.0
35.0
Pack Materials-Page 2
