2.3.2.7 Controller Area Network Controllers (DCAN)
Table 2-31. ZWT Controller Area Network Controllers (DCAN)
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
337
ZWT
CAN1RX
CAN1TX
CAN2RX
CAN2TX
CAN3RX
CAN3TX
B10
A10
H1
I/O
Pull Up
Programmable, CAN1 receive, or GIO
20uA
CAN1 transmit, or GIO
CAN2 receive, or GIO
CAN2 transmit, or GIO
CAN3 receive, or GIO
CAN3 transmit, or GIO
H2
M19
M18
2.3.2.8 Local Interconnect Network Interface Module (LIN)
Table 2-32. ZWT Local Interconnect Network Interface Module (LIN)
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
337
ZWT
LINRX
LINTX
A7
B7
I/O
Pull Up
Programmable, LIN receive, or GIO
20uA
LIN transmit, or GIO
2.3.2.9 Standard Serial Communication Interface (SCI)
Table 2-33. ZWT Standard Serial Communication Interface (SCI)
Terminal
Signal
Type
Default
Pull State
Pull Type
Description
Signal Name
337
ZWT
N2HET1[06]/SCIRX/EPWM5A
W3
N2
I/O
Pull Down Programmable, SCI receive, or GIO
20uA
N2HET1[13]/SCITX/EPWM5B
SCI transmit, or GIO
