5.7 Controller Area Network (DCAN)
The DCAN supports the CAN 2.0B protocol standard and uses a serial, multimaster communication
protocol that efficiently supports distributed real-time control with robust communication rates of up to 1
megabit per second (Mbps). The DCAN is ideal for applications operating in noisy and harsh
environments (e.g., automotive and industrial fields) that require reliable serial communication or
multiplexed wiring.
5.7.1 Features
Features of the DCAN module include:
•
•
•
•
•
•
•
•
•
•
•
•
•
Supports CAN protocol version 2.0 part A, B
Bit rates up to 1 MBit/s
The CAN kernel can be clocked by the oscillator for baud-rate generation.
64 mailboxes on each DCAN
Individual identifier mask for each message object
Programmable FIFO mode for message objects
Programmable loop-back modes for self-test operation
Automatic bus on after Bus-Off state by a programmable 32-bit timer
Message RAM protected by parity
Direct access to Message RAM during test mode
CAN Rx / Tx pins configurable as general purpose IO pins
Message RAM Auto Initialization
DMA support
For more information on the DCAN see the device Technical Reference Manual.
5.7.2 Electrical and Timing Specifications
Table 5-26. Dynamic Characteristics for the DCANx TX and RX pins
Parameter
MIN
MAX
15
Unit
ns
td(CANnTX)
td(CANnRX)
Delay time, transmit shift register to CANnTX pin(1)
Delay time, CANnRX pin to receive shift register
5
ns
(1) These values do not include rise/fall times of the output buffer.
