LM120, LM320-N
SNVS756C –APRIL 1998–REVISED APRIL 2013
www.ti.com
See Performance (Typical)
*Resistor tolerance of R4 and R5 determine matching of (+) and (−) outputs.
**Necessary only if raw supply filter capacitors are more than 2 inches from regulators.
Figure 20. ±15V, 1 Amp Tracking Regulators
Performance (Typical)
Load Regulation at ΔIL = 1A
10 mV
1 mV
Output Ripple, CIN = 3000 μF,
IL = 1A
100 μVrms
100 μVrms
Temperature Stability
+50 mV
+50 mV
Output Noise 10 Hz ≤ f ≤ 10 kHz
150 μVrms
150 μVrms
Light Controllers Using Silicon Photo Cells
*Lamp brightness increases until iI = 5V/R1 (iI can be set as low as 1 μA).
†Necessary only if raw supply filter capacitor is more than 2 inches from LM320MP.
14
Submit Documentation Feedback
Copyright © 1998–2013, Texas Instruments Incorporated
Product Folder Links: LM120 LM320-N
