LM118, LM218, LM318
FAST GENERAL-PURPOSE OPERATIONAL AMPLIFIERS
SLOS063A – JUNE 1976 – REVISED APRIL 1994
AVAILABLE OPTIONS
PACKAGE
CHIP CARRIER
V
max
IO
T
A
SMALL OUTLINE
(D)
CERAMIC DIP
(JG)
PLASTIC DIP
(P)
AT 25°C
(FK)
0°C to 70°C
–25°C to 85°C
–55°C to 125°C
10 mV
4 mV
4 mV
LM318D
LM218D
LM118D
—
—
—
LM318P
LM218P
LM118P
—
LM118FK
LM118JG
The D package is available taped and reeled. Add the suffix R to the device type (e.g., LM318DR).
schematic
BAL/COMP3
COMP2
BAL/COMP1
V
CC+
2 kΩ
150 kΩ
2 kΩ
5 kΩ
5 kΩ
100 pF
20 kΩ
20 kΩ
13 Ω
25 Ω
OUT
33 Ω
3.5 kΩ
6 pF
IN–
1 kΩ
1 kΩ
28 pF
5 kΩ
50 Ω
1.7 kΩ
4 kΩ
IN+
30 Ω
500 Ω
1.2 kΩ
1.2 kΩ
30 Ω
5.6 kΩ
20 kΩ
110 Ω
V
CC–
Component values shown are nominal.
2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
TI [ TEXAS INSTRUMENTS ]
