Circuit Data for Temperature Rise Curve
TO-220 Package (T)
Through hole electrolytic
Capacitors
Inductor
Diode
Through hole, Renco
Through hole, 5A 40V, Schottky
3 square inches single sided 2 oz. copper (0.0028″)
PC board
Figure 31. Junction Temperature Rise, TO-220
Circuit Data for Temperature Rise Curve
TO-263 Package (S)
Capacitors
Inductor
Diode
Surface mount tantalum, molded “D” size
Surface mount, Pulse Engineering, 68 μH
Surface mount, 5A 40V, Schottky
PC board
9 square inches single sided 2 oz. copper (0.0028″)
Figure 32. Junction Temperature Rise, TO-263
