DM385, DM388
SPRS821D –MARCH 2013–REVISED DECEMBER 2013
www.ti.com
8.18.2 Timer Electrical/Data Timing
Table 8-81. Timing Requirements for Timer
(see Figure 8-93)
OPP100/OPP120/
Turbo/Nitro
NO.
UNIT
MIN
4P(1)
4P(1)
MAX
1
2
tw(EVTIH)
tw(EVTIL)
Pulse duration, high
Pulse duration, low
ns
ns
(1) P = module clock.
Table 8-82. Switching Characteristics Over Recommended Operating Conditions for Timer
(see Figure 8-93)
OPP100/OPP120/
Turbo/Nitro
NO.
PARAMETER
Pulse duration, high
UNIT
MIN
4P-3(1)
4P-3(1)
MAX
3
4
tw(EVTOH)
tw(EVTOL)
ns
ns
Pulse duration, low
(1) P = module clock.
1
2
TCLKIN
3
4
TIMx_IO
Figure 8-93. Timer Timing
268
Peripheral Information and Timings
