8.18 Timers
The device has eight 32-bit general-purpose (GP) timers (TIMER8 - TIMER1) that have the following
features:
•
•
TIMER8, TIMER1 are for software use and do not have an external connection
Dedicated input trigger for capture mode and dedicated output trigger/pulse width modulation (PWM)
signal
•
•
•
Interrupts generated on overflow, compare, and capture
Free-running 32-bit upward counter
Supported modes:
–
–
–
Compare and capture modes
Auto-reload mode
Start-stop mode
•
TIMER[8:1] functional clock is sourced from either the DEVOSC, AUXOSC, AUD_CLK2/1/0, TCLKIN,
or SYSCLK18 27 MHz as selected by the timer clock multiplexers.
•
•
On-the-fly read/write register (while counting)
Generates interrupts to the ARM and Media Controller.
The device has one system watchdog timer that have the following features:
•
•
•
•
Free-running 32-bit upward counter
On-the-fly read/write register (while counting)
Reset upon occurrence of a timer overflow condition
The system watchdog timer has two possible clock sources:
–
–
RCOSC32K oscillator
RTCDIVIDER
•
The watchdog timer is used to provide a recovery mechanism for the device in the event of a fault
condition, such as a non-exiting code loop.
For more detailed information on the GP and Watchdog Timers, see the Timers and Watchdog Timer
chapters in the device-specific Technical Reference Manual.
