8.13.3.14.3 One DDR3 Device
A single DDR3 device is supported on the DDR EMIF consisting of one x16 DDR3 device arranged as
one bank (CS), 16 bits wide.
8.13.3.14.3.1 CK and ADDR_CTRL Topologies, One DDR3 Device
Figure 8-72 shows the topology of the CK net classes and Figure 8-73 shows the topology for the
corresponding ADDR_CTRL net classes.
