CC1110Fx / CC1111Fx
S0CON (0x98) - CPU Interrupt Flag 2
Bit
Field Name
Reset
R/W
Description
7:2
0
R/W
Not used
1
0
R/W
AES interrupt. ENCIF has two interrupt flags, ENCIF_1 and ENCIF_0. Interrupt
source sets both ENCIF_1and ENCIF_0, but setting one of these flags in SW will
generate an interrupt request. Both flags are set when the AES co-processor
requests the interrupt.
ENCIF_1
0
1
Interrupt not pending
Interrupt pending
0
0
R/W
AES interrupt. ENCIF has two interrupt flags, ENCIF_1 and ENCIF_0. Interrupt
source sets both ENCIF_1and ENCIF_0, but setting one of these flags in SW will
generate an interrupt request. Both flags are set when the AES co-processor
requests the interrupt.
ENCIF_0
0
1
Interrupt not pending
Interrupt pending
S1CON (0x9B) - CPU Interrupt Flag 3
Bit
Field Name
Reset
R/W
Description
7:6
0
R/W
Not used
1
0
R/W
RF general interrupt. RFIF has two interrupt flags, RFIF_1 and RFIF_0. Interrupt
source sets both RFIF_1and RFIF_0, but setting one of these flags in SW will
generate an interrupt request. Both flags are set when the radio requests the
interrupt.
RFIF_1
0
1
Interrupt not pending
Interrupt pending
0
0
R/W
RF general interrupt. RFIF has two interrupt flags, RFIF_1 and RFIF_0. Interrupt
source sets both RFIF_1and RFIF_0, but setting one of these flags in SW will
generate an interrupt request. Both flags are set when the radio requests the
interrupt.
RFIF_0
0
1
Interrupt not pending
Interrupt pending
SWRS033H
Page 66 of 246
