2.3.3.4 Timer
Table 2-27. Timer/Timer4 Signals Description
TYPE
[3]
SIGNAL NAME [1]
SIGNAL NAME [1]
SIGNAL NAME [1]
SIGNAL NAME [1]
DESCRIPTION [2]
ZCE BALL [4]
ZCZ BALL [4]
timer4
timer5
timer6
timer7
Timer trigger event / PWM out
I/O
C15, C18, K17,
V10
A15, C17, J16,
R7
Table 2-28. Timer/Timer5 Signals Description
TYPE
DESCRIPTION [2]
[3]
ZCE BALL [4]
ZCZ BALL [4]
Timer trigger event / PWM out
I/O
D19, H19, R19,
V8
D17, F17, M18,
T6
Table 2-29. Timer/Timer6 Signals Description
TYPE
DESCRIPTION [2]
[3]
ZCE BALL [4]
ZCZ BALL [4]
Timer trigger event / PWM out
I/O
E17, H18, P17,
U8
D18, F18, M17,
U6
Table 2-30. Timer/Timer7 Signals Description
TYPE
DESCRIPTION [2]
[3]
ZCE BALL [4]
ZCZ BALL [4]
Timer trigger event / PWM out
I/O
B15, B19, F19,
W9
C16, D14, E18,
T7
