2.3.3.2 eHRPWM
Table 2-21. eHRPWM/eHRPWM0 Signals Description
TYPE
[3]
SIGNAL NAME [1]
ehrpwm0A
DESCRIPTION [2]
eHRPWM0 A output.
ZCE BALL [4]
A18
ZCZ BALL [4]
O
A13, A17
B13, B17
A16, C12
ehrpwm0B
eHRPWM0 B output.
O
I
B18
A17
ehrpwm0_synci
Sync input to eHRPWM0 module from an
external pin
ehrpwm0_synco
Sync Output from eHRPWM0 module to an
external pin
O
I
U12, V2, W4
B17
R4, U12, U2, V14
B16, D12
ehrpwm0_tripzone_input
eHRPWM0 trip zone input
Table 2-22. eHRPWM/eHRPWM1 Signals Description
TYPE
[3]
SIGNAL NAME [1]
DESCRIPTION [2]
eHRPWM1 A output.
ZCE BALL [4]
ZCZ BALL [4]
ehrpwm1A
O
O
I
U5
V5
V4
U14, U3
T14, U4
R13, U1
ehrpwm1B
eHRPWM1 B output.
ehrpwm1_tripzone_input
eHRPWM1 trip zone input
Table 2-23. eHRPWM/eHRPWM2 Signals Description
TYPE
[3]
SIGNAL NAME [1]
DESCRIPTION [2]
eHRPWM2 A output.
ZCE BALL [4]
ZCZ BALL [4]
ehrpwm2A
O
O
I
U1, V15
U2, W16
T12, V1
R1, U10
R2, T10
R3, T11
ehrpwm2B
eHRPWM2 B output.
ehrpwm2_tripzone_input
eHRPWM2 trip zone input
